Oil-free up to 580 psig: the BOGE K BOOSTER
The BOGE K BOOSTER oil-free piston compressor is the ideal solution for oil-free compressed air, particularly for high pressure requirements of up to 580 psig. The innovative pushrod system works without oil while being low maintenance and causing little wear. The BOGE K BOOSTER is the new alternative for maximum pressure oil-free compression.
Product
Oil free inlet pressure piston compressor, direct coupled
advantages
- oil-free compressed air
- directly coupled
- with receiver
- designed for 100% duty cycle
- high pressures
OTHER CONSTRUCTION VARIANTS
| BOGE | Pressure | Effective Delivery Volume* 60 Hz | Motor Power | Dimensions W × H × D | Weight | |
|---|---|---|---|---|---|---|
| type | psig | m3/min | cfm | hp | inch | lbs |
| K 8 N Booster | 300 | 1.310 | 20 | 7.5 | 31 x 40 x 36.5 | 460 |
| K 8 N Booster | 400 | 1.250 | 28 | 7.5 | 31 x 40 x 36.5 | 460 |
| K 8 N Booster | 500 | 1.200 | 35 | 7.5 | 31 x 40 x 36.5 | 460 |
| K 8 N Booster | 580 | 1.160 | 40 | 7.5 | 31 x 40 x 36.5 | 460 |
| K 15 N Booster | 300 | 2.620 | 40 | 15 | 35 x 59 x 36.5 | 855 |
| K 15 N Booster | 400 | 2.500 | 56 | 15 | 35 x 59 x 36.5 | 855 |
| K 15 N Booster | 500 | 2.390 | 70 | 15 | 35 x 59 x 36.5 | 855 |
| K 15 N Booster | 580 | 2.320 | 80 | 15 | 35 x 59 x 36.5 | 855 |
* Effective free air delivery as per ISO 1217:2009 Appendix C, measured at 80% maximum pressure.
