Screw Compressor C series 10 hp fixed speed
Needs little space, gives you full power
The compact compressors of the C Series work reliably and safely when large amounts of compressed air are required. Thanks to the integrated design, the connection distances are short, meaning pressure losses are minimal. The compressors need exceptionally low energy and still get full power.
Product
Compact class screw compressor, oil lubricated
advantages
- compact design
- extremely quiet
- maximum efficiency
OTHER CONSTRUCTION VARIANTS
| BOGE | Pressure | Effective Delivery Volume 60 Hz | Motor Power | Dimensions W × H × D | Weight | |
|---|---|---|---|---|---|---|
| type | psig | m3/min | cfm | hp | inch | lbs |
| C 9 N | 100 | 1.250 | 44 | 10 | 19 x 35.7 x 37.6 | 474 |
| C 9 N | 125 | 1.180 | 42 | 10 | 19 x 35.7 x 37.6 | 474 |
| C 9 N | 150 | 1.060 | 37 | 10 | 19 x 35.7 x 37.6 | 474 |
| C 9 N | 190 | 0.870 | 31 | 10 | 19 x 35.7 x 37.6 | 474 |
